Product Specifications
Model NO.YC-PVCB
CertificationVDE, CCC, CE
VoltageHigh Voltage / DC1000V
Protection GradeIP56 / IP65
Shell MaterialStainless Steel / Aluminium
Thickness1.0 / 1.2 / 1.5 / 2.0mm
ApplicationSolar PV System, High-rise Buildings
InstallationWall-Mount
Product Overview
PV array Combiner Box is designed to reduce the wiring between solar modules and inverters, improving system reliability and facilitating easy maintenance. Users can connect series of photovoltaic cells into the combiner box, which features lightning protectors and circuit breakers before outputting to the inverter.
| Input Range |
1-30 ways |
Output Range |
1-5 ways |
| Working Temp |
-80°C to 60°C |
Elevation |
≤ 5500mm |
Key Features
- ✔Supports 1/2/4/6/8/10/12/16/24-way PV array parallel input.
- ✔Equipped with special DC fuses for both positive and negative electrodes.
- ✔Wide DC voltage input capability up to 1000VDC.
- ✔Anti-reverse connection module to prevent back-end device damage.
- ✔Professional lightning protection modules included.
- ✔IP65 protection degree suitable for outdoor harsh environments.
Profile
The manufacturer is an industry and trade integration enterprise focusing on research, development, production, and service of high and low voltage electrical appliances. Key products include frame circuit breakers (ACB), vacuum circuit breakers, plastic case circuit breakers (MCCB), AC contactors, and PV combiner boxes. Adhering to the "quality-oriented" policy, the enterprise implements international standards for quality and brand competition. Continuous innovation and market-oriented efficiency drive the delivery of high-quality products and personalized services to global customers.
Frequently Asked Questions
What is the protection rating of this PV combiner box?
The product features IP56 to IP66 protection degrees, making it suitable for outdoor installation and harsh environments.
What materials are available for the enclosure?
The shell can be made from high-quality Stainless Steel or Aluminium Profile, depending on your requirements.
Does the box include safety protection?
Yes, it includes DC fuses for both positive and negative terminals, lightning protection modules, and over-voltage/over-current protection.
Can I customize the number of input strings?
Yes, we support customization for 1 to 30 input ways and 1 to 5 output ways to fit your specific solar system configuration.
What is the standard lead time for bulk orders?
For orders between 1 and 1000 pieces, the standard lead time is approximately 15 days. Larger quantities are subject to negotiation.
What is the maximum DC voltage support?
The combiner box is designed for high voltage applications and can reach up to 1000VDC.
